Aftermarket Hydraulic Breakers Seal Kit Repair Parts for Furukawa
Engineered for reliability, our Furukawa Hydraulic Breaker Seal Kits deliver excellent sealing performance, extend breaker lifespan, and ensure stable operation under the toughest working environments such as mining, demolition, and quarrying.
| Material | NBR/ PTFE/ ACM/ VMQ/ FKM/ HNBR/ EPDM/ Silicone and etc |
|---|---|
| MOQ | 5 Pieces |
| Pressure | Up to 690bar(10000psi) |
| Working Temperature | -40–120℃(according to the material) |
| Color | Black/Orange/Brown/White/Brown |
Quick Quote Request
Kinton Seals is trusted by professionals worldwide for providing high-quality seal kits for excavators, dozers, loaders, and other heavy machinery, ensuring reliable performance and long-lasting durability.
Furukawa hydraulic breakers are well-known for their high impact power, efficiency, and durability, making them a trusted choice for construction, quarrying, tunneling, and mining projects. However, to maintain optimal performance, the hydraulic sealing system must always be in top condition.
Our Furukawa Seal Kits are precision-engineered to match OEM specifications, ensuring a perfect fit and reliable sealing. By replacing worn seals in time, you prevent issues such as hydraulic oil leakage, power loss, excessive wear, and costly equipment downtime. With our kits, your breaker regains its original striking force, extending both productivity and equipment lifespan.
Quality Manufacturing Process
Each seal kit undergoes strict quality checks to ensure long-lasting performance:
Precision Material Weighing
Each raw material block is carefully weighed with high-accuracy equipment before processing. This ensures that every seal ring starts with the exact material volume required for its specific size and application, preventing inconsistencies in density or performance.
Mold Preparation & Material Placement
After weighing, the prepared material is positioned onto the appropriate mold. Our workshop is equipped with a wide variety of molds to match different seal ring diameters and cross-sections. The correct mold selection guarantees precise shaping, while careful placement avoids defects such as uneven thickness.
High-Pressure Compression Molding
The molds are then set under specialized compression machines, where controlled pressure and temperature are applied. This process allows the material to be fully formed into a durable seal with consistent hardness and elasticity. Strict monitoring ensures every batch meets dimensional accuracy and structural integrity.
Rigorous Quality Inspection
Each batch of seals undergoes rigorous testing after molding. Technicians check for dimensional accuracy, surface smoothness, hardness, and sealing resilience. Any defective products are filtered out, ensuring that only seals with stable performance and long service life proceed to packaging.
In conclusion, choosing our Furukawa Hydraulic Breaker Seal Kit helps operators achieve reduced downtime, lower maintenance costs, and extended equipment life, making it the ideal replacement solution for any heavy-duty Furukawa breaker.
Key Features & Benefits
- Exact OEM Fit – Designed to meet or exceed Furukawa factory standards.
- Leak-Proof Performance – Maintains hydraulic oil pressure and prevents contamination.
- Long Service Life – Manufactured with premium elastomers for heat and wear resistance.
- Boosts Breaker Power – Keeps hydraulic pressure stable to maximize striking force.
- Easy Maintenance – Kits include all necessary seals for quick replacement.
- Broad Applications – Reliable in construction, demolition, quarrying, and mining.
Compatible Breaker Models
Our seal kits are available for a wide range of Furukawa breaker models, including but not limited to:
- HB Series: HB05, HB10, HB15, HB20, HB30, HB40, HB50
- Fx Series: Fx35, Fx45, Fx55, Fx65, Fx85, Fx125, Fx175, Fx225
- F Series: F2, F4, F5, F9, F12, F19, F22, F27, F35
- Other models available on request
| Part Numbers | |||||||
|---|---|---|---|---|---|---|---|
| F1 | F2 | F3 | F4 | F5 | F6 | F9 | F11 |
| F12 | F19 | F22 | F35 | F45 | FX35 | FX45 | FXJ375 |
| FXJ475 | HB1G | HB2G | HB3G | HB5G | HB8G | HB10G | HB15G |
| HB18G | HB20G | HB30G | HB50G | HB200 | HB300 | HB400 | HB700 |
| HB1200 | HB1500 | ||||||
If you are uncertain about compatibility, please provide your breaker’s serial number or model, and our team will assist you.
Applications
Our Furukawa Seal Kits are engineered for diverse working environments, including:
- Urban Demolition & Recycling – Breaking reinforced concrete and structures
- Mining & Quarrying – Crushing rock and heavy ore under extreme loads
- Infrastructure Projects – Road, bridge, and tunnel construction
- General Construction – Heavy-duty excavation and foundation works
Whether in harsh outdoor sites or continuous industrial use, these kits guarantee maximum sealing reliability and breaker protection.
Seal Placement
Seals are strategically installed in piston, cylinder, valve, and tie rod areas of breakers. They work together to:
- Prevents leakage of hydraulic oil under high pressure.
- Protecting internal components from dust, water, and abrasive particles.
- Provides smooth piston and connecting rod movement and consistent impact force.
- Reduces wear on metal components by maintaining proper lubrication.
Seals are strategically placed in the piston, cylinder, tie rods, and valve areas, ensuring full hydraulic protection and preventing premature wear of critical components.
Material Overview for Seal Kits
Our seal kits are manufactured using carefully selected materials, each optimized for breaker working conditions:
Nitrile Rubber Buna(NBR, BUNA-N)
Temperature Range:-30 to 125 ℃
Hardness:60-90 Shore A
Color: Black
Use: Oil & Water Resistance Situation Advantage: Excellent oil resistance, performance and stability, widely used, cheaper
Fluororubber(FKM,FPM)
Temperature Range:-20 to 250℃
Hardness:70-90 Shore A
Color: Black/Brown/Green
Use: Oil & Chemical Resistance Situation
Advantage: Wear resistance, acid and alkali resistance, high temperature resistance situation
Silicone (VMQ )
Temperature Range: -60 to 225 ℃
Hardness: 50-70 Shore A
Color: Red/Black/Blue/White/Transparent, etc
Use: Heat& Food Situation(FDA, RoHS Approved)
Advantage: Good heat resistance, cold resistance, lubrication oil resistance, water resistance safety & reliable to human body
Ethylene Propylene Rubber(EPDM, EPM)
Temperature Range:-50 to 150 ℃
Hardness: 60-90 Shore A
Color: Black
Use: Ozone, water vapor situation
Advantage: Excellent oxidation resistance ozone resistance and erosion resistance
Perfluoroelastomer(FFKM, FFPM)
Temperature Range: -42 to 327 ℃
Hardness:60-95 Shore A
Color: Black / White
Advantage: Long-term, proven performance, can mean less frequent seal changes, repairs and inspections, increasing process and equipment uptime in productivity and yield.
Neoprene Rubber(CR )
Temperature Range:-30 to 125 ℃
Hardness:60-90 Shore A
Color: Black
Use: Oil & Water Resistance Situation Advantage: Excellent oil resistance, performance and stability, widely used, cheaper
This material combination ensures that your breaker remains protected from oil leakage, abrasion, and extreme temperatures, delivering consistent performance in heavy-duty jobs.
Why Choose Our Fine Breaker Seal Kits?
- Trusted quality with OEM-level precision
- Long-lasting materials built for tough environments
- Fast shipping and reliable customer service
- Available for multiple breaker models
At Kinton Seals, we understand that reliable delivery is just as important as product quality. Our goal is to ensure that every order of Seal Kits for excavators, bulldozers, wheel loaders, and other heavy machinery reaches our customers safely, on time, and in perfect condition.
Packaging & Protection
- Standard Export Packaging – Each seal kit is carefully packed in moisture-proof and dust-proof bags, ensuring seals remain clean and undamaged during storage and transportation.
- Layered Protection – Kits are placed in sturdy cartons, and for bulk shipments, cartons are further reinforced with pallets and stretch film to minimize impact during handling and transit.
- Customization Options – We provide OEM/ODM packaging services, including branded boxes, barcodes, and special instructions, helping partners strengthen their brand presence in local markets.
- Extra Protection – For bulk shipments, cartons and pallets are reinforced to reduce the risk of damage in transit.
Order Processing & Lead Time
- Standard Seal Kits – For large quantity orders, lead time is usually 7–10 working days, as each kit requires precise matching of every seal, followed by labeling and packaging.
- Custom Seal Kits – For tailored requirements or non-standard models, production and assembly typically take 15–30 days, especially if new tooling or mold development is required.
- Sample Orders – Small batch or sample kits can often be prepared faster, subject to stock availability.
Delivery Options
- Air Freight for urgent orders
- Sea Freight for bulk shipments
- Courier Express (DHL, FedEx, UPS) for small packages and samples
